1.7 oz 50 ml x 50 ml
Length and width 4" x 1-7/8"
Overall length 9-1/4"
Thrusting force 600 lbs.
Mechanical advantage 22 to 1
Ratio 1 to 1

6 oz. 80 ml x 80 ml
Length and width 5" x 1-5/8"
Overall length 10"
Thrusting force 600 lbs.
Mechanical advantage 22 to 1
Ratio 1 to 1

50 ml x 50 ml
Length and width 4-1/2" x 1-3/4"
Overall length 9"
Thrusting force 400 lbs.
Mechanical advantage 18 to 1
Ratio 1 to 1
Designed to hold cartridge in place by flange on rear of gun

70 ml x 70 ml
Length and width 4-1/2" x 1-3/4"
Overall length 10"
Thrusting force 400 lbs.
Mechanical advantage 18 to 1
Ratio 1 to 1
Designed to hold cartridge in place by flange on rear of gun

300 ml x 100 ml
Length and width 8-7/8" x 3-1/4"
Overall length 13-1/2"
Thrusting force 750 lbs.
Mechanical advantage 22 to 1
Ratio 3 to 1

50 ml x 25 ml
Length and width 4-1/2" x 1-3/4"
Overall length 9"
Thrusting force 400 lbs.
Mechanical advantage 18 to 1
Ratio 2 to 1
Designed to hold cartridge in place by flange on rear of gun

7 oz. 100 ml x 100 ml
Length and width 8-15/16" x 3-3/16"
Overall length 13-1/4"
Thrusting force 600 lbs.
Mechanical advantage 18 to 1
Ratio 1 to 1

150 ml x 150 ml
Length and width 8-15/16" x 3-3/16"
Overall length 13-1/4"
Thrusting force 600 lbs.
Mechanical advantage 18 to 1
Ratio 1 to 1
Carriage length is adjustable
Can be converted to 100 ml x 100 ml, 11 fluid oz.

150 ml x 150 ml
Length and width 8-15/16" x 4-3/16"
Overall length 13-1/4"
Thrusting force 650 lbs.
Mechanical advantage 24 to 1
Ratio 1 to 1
Can be converted to 150 ml x 75 ml
75 ml push washers included.

300 ml x 300 ml
Length and width 9-1/2" x 4-1/4"
Overall length 14"
Thrusting force 650 lbs.
Mechanical advantage 24 to 1
Ratio 1 to 1
Push rods are 3/8" case hardened steel. Supplied with side handle for added stability. Handle can be used on either side.

300 ml x 300 ml
Length and width 8-7/8" x 4-3/16"
Overall length 13-1/2"
Thrusting force 750 lbs.
Mechanical advantage 22 to 1
Ratio 1 to 1
Push rods are 3/8" case hardened steel. Supplied with side handle for added stability. Handle can be used on either side. Can be converted to 300 ml x 150 ml, 2 to 1 gun.

Buy Online Now

300 ml x 300 ml
Weight 2.5 lbs.
Thrusting force 550 lbs.
Mechanical advantage 22 to 1
Ratio 1 to 1
Designed for the DIY user

300 ml x 300 ml
Length and width 8" x 4-3/16"
Overall length 14-1/8"
Thrusting force 850 lbs.
Mechanical advantage 24 to 1
Ratio 1 to 1
Uses 3/8" case hardened rods and cam. All three rods push the washers for added ease of dispensing product. Supplied with side handle for added stability. Handle can be used on either side.

Buy Online Now

300 ml x 300 ml
Length and width 8" x 4-3/16"
Overall length 14-1/8"
Thrusting force 850 lbs.
Mechanical advantage 24 to 1
Ratio 1 to 1
Uses 3/8" case hardened rods and cam. All three rods push the washers for added ease of dispensing product. Also has follower plates to stabilize cartridge. Supplied with side handle for added stability. Handle can be used on either side. Fits Simpson Dual Cartridge Systems.

300 ml x 150 ml
Length and width 8-7/8" x 4-3/16"
Overall length 14-1/8"
Thrusting force 850 lbs.
Mechanical advantage 24 to 1
Ratio 2 to 1
Comes with support brackets on rear carriage plate to better stabilize cartridge. Uses 3/8" case hardened rods and cam. All three rods push the washer for added ease of dispensing product. Supplied with side handle for added stability. Handle can be used on either side.

300 ml x 150 ml
Length and width 8-7/8" x 4-3/16"
Overall length 13-1/2"
Thrusting force 750 lbs.
Mechanical advantage 22 to 1
Ratio 2 to 1
Uses 3/8" case hardened rods and cam. Can be converted to 300 ml x 300 ml. Supplied with side handle for added stability. Handle can be used on either side.

300 ml x 300 ml
Length and width 8-15/16" x 4-1/8"
Overall length 14-1/2"
Thrusting force 850 lbs.
Mechanical advantage 24 to 1
Ratio 1 to 1
Uses 3/8" case hardened rods and cam. Full, rounded, heavy duty carriage. All three rods, push the washers for added ease of dispensing product. Handle can be used on either side.

600 ml x 300 ml
Length and width 9-1/8" x 4-7/8"
Overall length 14-1/4"
Thrusting force 850 lbs.
Mechanical advantage 24 to 1
Ratio 2 to 1
Uses 3/8" case hardened rods and cam. All three rods push the washers for added ease of dispensing product. Supplied with side handle for added stability. Handle can be used on either side.

75 ml x 75 ml or 100 ml x 100 ml
Length and width 6-1/2" x 3-3/16"
Overall length 11-3/4"
Thrusting force 700 lbs.
Mechanical advantage 24 to 1
Ratio 1 to 1
Has 3/8" case hardened rods and cam. Includes 2 sets of push rods and seals.

300 ml x 75 ml
Length and width 9-7/8" x 2-1/8"
Overall length 14-7/8"
Thrusting force 600 lbs.
Mechanical advantage 22 to 1
Ratio 4 to 1

Mechanical Dual Cartridge Gun
Weight 2.87 lbs
Fits 200 ml x 200 ml Dual Cartridge
Max thrusting force 400 lbs.
Mechanical advantage 22 to 1
Ratio 1 to 1

300 ml x 30 ml
Length and width 9-1/8" x 1-15/16"
Overall length 14-1/2"
Thrusting force 600 lbs.
Mechanical advantage 18 to 1
Ratio 10 to 1

750 ml x 75 ml
Length and width 10" x 3-1/8"
Overall length 14-1/2"
Thrusting force 800 lbs.
Mechanical advantage 24 to 1
Ratio 10 to 1
Uses 3/8" case hardened rods and cam. Works with ITW 10 to 1 cartridge.

100 ml x 100 ml
Length and width 6-1/2" x 1-3/4"
Overall length 11-1/2"
Thrusting force 600 lbs.
Mechanical advantage 24 to 1
Ratio 1 to 1
